Updated By Teckwrap Craft On June 1, 2024
How To Put Vinyl On A Curved Surface
Table of Contents
- Application Of Vinyl To Curved Surfaces: Basic Steps
- Step 1: Vinyl Designs
- Step 2: Cut, Weed, And Transfer
- Step 3: Remove The Vinyl Backing Paper
- Step 4: Stabilize The Surface
- Step 5: Apply Vinyl
- Step 6: Burnishing And Sealing The Vinyl Decal
- Tips and Tricks On How To Easily Apply Vinyl On A Curved Surface
- Using The Self-Hinge Method
- Frequently Asked Questions
You may be wondering how to put vinyl on a curved surface effortlessly. Most surfaces that you will be putting vinyl on are mugs or cups, water bottles, tumblers, glasses, vases, decorations, and a lot more.
Applying vinyl on a curved surface is different from flat surfaces. If you find yourself struggling to apply vinyl on curved pieces because of wrinkles and crease formation, then this guide is made for you.
Application Of Vinyl To Curved Surfaces: Basic Steps
If you have been crafting for quite some time now, you most probably know the basic steps when working with vinyl. You need to design, cut, weed, and transfer. If you want a refresher or know more details on how to apply vinyl on a project surface, you may want to read this blog post.
Here are the basic steps on how to put vinyl on a curved surface:
Step 1: Vinyl Designs
To make designing easier for you, the Cricut Design Space can be very helpful. You can use the Cricut Design Space to turn your dream design into reality. If you are running dry on design ideas, it has design suggestions that you can conveniently use. You can read this article about color attachment using Cricut Design Space.
Step 2: Cut, Weed, And Transfer
Once you have selected the vinyl design and adjusted its size on the software, you need to cut it using a cutting machine and weed out excess material leaving you with just the entire vinyl decal. Also, do keep a utility knife around for you may need this to cut the vinyl. Once you have accomplished this, it is time to use your transfer tape.
The transfer tape is the material you need to transfer your vinyl decal to the curved surface. Working with rounded surfaces can be a bit challenging. Thus, you can start on one side. Slowly, slide off the transfer paper backing as you move across the vinyl design.
When your vinyl and transfer tape are stuck together, you can use a scraper tool like a squeegee to burnish them. Burnishing helps the vinyl to stick better onto the transfer tape and for the easy removal of the backing sheet.
Step 3: Remove The Vinyl Backing Paper
Snip the bottom and top portions of your backing paper. Then peel off the backing paper. You are then ready to transfer the vinyl to your curved surface.
Step 4: Stabilize The Surface
A major challenge that you may experience working with a curved surface is how to make it stable while you are applying vinyl. The project can roll away while you are applying vinyl and you wouldn't want that to happen.
To stabilize your curved surface you can sandwich it using rice bags or bean bags. If you have more time on your hands, you can try making a similar setup like the image below to make the transfer process smooth and effortless.
Step 5: Apply Vinyl
As soon as the surface is stable and ready, you can easily apply your vinyl design. You can begin to carefully fold the entire vinyl decal and remove the backing paper one side at a time. While you remove the paper backing, firmly press the transfer tape to the curved surface. Once one side is done, you can repeat the technique on the other side.
Step 6: Burnishing And Sealing The Vinyl Decal
Your goal is for the vinyl design to adhere to the surface completely and that is possible with the help of burnishing. Peel off the transfer paper very slowly at an angle keeping it closer to the surface. Press down the vinyl design while doing so to ensure that it sticks to the curved surface.
If you don't want to seal the vinyl design after you have applied it, that is alright. However, if you want to be on the safe side, sealing the vinyl on the curved surface using Mod Podge is to your advantage. You need to patiently wait for 72 hours for the vinyl to completely cure. Then, that’s it!
Tips and Tricks On How To Easily Apply Vinyl On A Curved Surface
If you hate wrinkled vinyl and stubborn air bubbles, you can remedy this by lightly heating the vinyl with a heat gun or hairdryer. Peel off the vinyl slowly to remove the bubbles and wrinkles. If you have managed to remove all these, you can press back the vinyl in place.
Using The Self-Hinge Method
The hinge method begins when you have applied transfer paper over your decal and you are removing the vinyl backing. Do not discard the vinyl backing for you will need this to hinge your design. To make the hinge, you need to cut the backing in half all the way to the center.
You will re-apply the backing to the design while leaving a small gap in the middle. Position your design with the transfer tape on the curved surface. Slowly trim or fold back one section of the backing and press the decal to the curved surface avoiding bubbles and wrinkles. Do the same to the other side.
This method may require an extra step but it can ensure a faster and more efficient transfer on rounded surfaces. It is best to use the technique that you find easy to work with. What’s important is to achieve the goal of transferring the decal to the surface.
Frequently Asked Questions
It’s Easy!
You now know how to put vinyl on a curved surface. When you are doing it for the first time you can expect some hurdles but you can learn from experience and be a better crafter for your next project. You may find these two blog articles helpful when working on curved surfaces - applying vinyl on mugs and wine glasses.
For premium-quality permanent adhesive craft vinyl in an extensive variety of colors, finishes, and textures, visit TeckWrap Craft. You can also get necessary accessories from us such as transfer tape, squeegee, and so on.
